Determine the unknown quantity: a. [(η^5-C5 H5) W(CO)x]2 (has W-W single bond) B. c. [(CO)3 Ni-C

Determine the unknown quantity: a. [(η^5-C5 H5) W(CO)x]2...

Key Concepts

Ligand Characteristics (CO and NO Ligands)

Ligands like carbonyl (CO) and nitrosyl (NO) exhibit distinct electron-donating properties that must be considered during electron counting. While CO typically acts as a two-electron donor, NO can bind either in a bent or linear fashion, with linear M–N–O configurations usually behaving as a three-electron donor. Knowledge of these properties is crucial in determining the number or identity of unknown ligands in a complex.

Hapticity and Ligand Donation

Hapticity refers to the number of contiguous atoms in a ligand that are coordinated to a metal center, which influences the number of electrons the ligand donates. Ligands such as cyclopentadienyl (?^5-C5H5) have a specific hapticity that dictates their electron donation, and understanding this is important when performing electron counts for complexes containing such ligands.

Metal–Metal Bonding

Metal–metal bonding involves the sharing of electrons between two metal atoms. In complexes that include such bonds, these bonds contribute electrons to the overall electron count. Recognizing and accounting for the electrons involved in metal-metal interactions is essential when applying electron counting and the 18-electron rule to determine unknown quantities in the complex.

18?Electron Rule

The 18-electron rule is a guideline stating that many stable organometallic complexes have a total of 18 valence electrons. Achieving an 18-electron configuration is analogous to a noble gas electron configuration and is used to rationalize the preferred electron counts in complexes, helping to determine the number of ligands or unknown ligands in a complex.

Electron Counting

Electron counting is a systematic method used to calculate the total number of electrons around a metal center by adding its valence electrons, the electrons donated by the ligands, and any contributions from metal-metal bonds. This process is fundamental in organometallic chemistry for predicting the stability and reactivity of complexes.

Transcript

00:01 So first of all we have given bracket neta 5 c5 h5 then w co x and whole 2 okay so now neta 5 this indicates that this c5 h5 is a 5 electron donor w that is tungsten and that is from the group of chromium okay so that is a 6 valence electron we have here co so that is 2 electron donor okay and since here we have whole 2 or all over the bracket so that's why we will multiply each of them by 2 so this will be 2 multiplied by 5 plus 2 multiplied by 6 plus 2 multiplied by 2 x okay we have 2 electron multiplied by x and multiplied by 2 for this one and that's equal to again we will multiply by 2 so this will be 2 multiplied by 18 so this will be 10 plus 12 plus 4 x is equals to 36 solving this we will get x is equals to 3 then we have b part and this will be br co x re and then we have double bond carbon and oxygen atoms are there okay like this so this is a ligand here we have okay so now for bromine so we have it donates 1 electron plus 2 x again okay because co we have this is 2 electron donor then we have re so this is from manganese family this has 7 valence electron plus 2 will be there okay for this one and that's equal to 18 so solving this so we will write 2 x is equals to 18 8 sorry on solving we will get 8 and this will be x is equals to 4 okay so we are doing all this by 18 electron rule okay so we are summing up all the ligands and metal electrons and then this is equals to 18 okay and now moving on to next part so we have so this is co whole 3 ni co this is cobalt then co whole 3 and this is overall whole 2 okay so this will be so now we have co this is 2 electron donor so this will be by 2 right plus for nickel so that has 10 valence electron then we have cobalt that has 9 valence electron then we have plus 3 multiplied by 2 again and here we have x actually sorry this is x here so now we have a bond between nickel and cobalt so for that we will add 2 and minus x is equals to 36 okay because we have this single bond okay so that's why again we will multiply 18 by 2 and this will be 36 right so now solving this we will get so this will be 6 plus 10 plus 9 plus 6 plus 2 minus x…
