Chapter Questions
A circuit that has more than one path to the power source is aa. series circuit.b. open circuit.c. parallel circuit. d. short circuit.
When a conductor is moved through a magnetic field, a voltage is induced in the conductor. However, current won't flow through the conductor unless it'sa. formed into a coil.b. connected in a complete circuit.c. moved very quickly through the magnetic field.d. made of copper.
What is the voltage of a circuit having a current flow of 3 amperes and a resistance of $4 \mathrm{ohms}$ ?a. $0.12 \mathrm{~V}$b. $12 \mathrm{~V}$c. $7 \mathrm{~V}$d. $36 \mathrm{~V}$
A circuit that has an incomplete path for current to flow is calleda. a grounded circuit.b. an open circuit.c. a short circuit.d. a closed circuit.
EMF is measured ina. watts.b. ohms.c. amperes.d. volts.
An ohmmeter is always connected to an electrical circuita. in series.b. to measure voltage.c. after the component being tested has been isolated from the rest of the electrical system.d. after the power has been turned on.
The terminals of a diode are thea. gate, anode, and cathode.b. primary and secondary.c. emitter, collector, and base.d. anode and cathode.
What would be the resistance of a 12-volt lightbulb with 5 amperes flowing through it?a. 2.4 ohmsb. 2.4 voltsc. $0.416 \mathrm{ohms}$d. 0.417 volts
An ammeter is always connected to an electrical circuita. after it has been isolated from the rest of the electrical system.b. in parallel.c. in series.d. after the power has been turned on.
The conventional current flow theory can best be described asa. electron flow from the negative terminal to the positive terminal.b. electron flow from the cathode terminal to the anode terminal.c. electron flow from $\mathrm{AC}$ to $\mathrm{DC}$ and then back to AC.d. electron flow from the positive terminal to the negative terminal.
Electrical current flow is measured ina. ohmsb. amperesc. wattsd. volts
The abbreviation "AC" stands for _________.
The abbreviation "DC" stands for _________.
With a _________ , you can separate the desired subsystem, such as the ignition system, from the rest of the schematic.
Which theory of electricity is used in explanation of electrical circuits in the power equipment engine industry?a. Electronb. Electro-conventionalc. Conventionald. Nonconventional
