Identify the thermodynamic processes in compressor cycle using a PV diagram.
Added by Sara F.
Close
Step 1
The first process in a compressor cycle is the intake or suction process. This is represented by the line from point A to point B on the PV diagram. During this process, the compressor draws in the working fluid (usually a gas) from the surroundings at a low Show more…
Show all steps
Your feedback will help us improve your experience
Morgan Cheatham and 59 other Physics 101 Mechanics educators are ready to help you.
Ask a new question
Labs
Want to see this concept in action?
Explore this concept interactively to see how it behaves as you change inputs.
Key Concepts
Recommended Videos
In a standard vapour compression refrigeration cycle, operating between an evaporator temperature of -18°C and a condenser temperature of 36°C, the enthalpy of the refrigerant, Freon-12, at the end of compression is 225 kJ/kg. on T-s plane. Show the cycle diagram in the PV and TS diagram; Calculate: (ii) The C.O.P. of the cycle; (iii) The refrigerating capacity; (iv) The compressor power assuming a refrigerant flow rate of 1 kg/min.
Sri K.
Mahendra K.
A refrigerator using $\mathrm{R}-134 \mathrm{a}$ is located in a $20^{\circ} \mathrm{C}$ room. Consider the cycle to be ideal, except that the compressor is neither adiabatic nor reversible. Saturated vapor at $-20^{\circ} \mathrm{C}$ enters the compressor, and the $R-134$ a exits the compressor at $50^{\circ} \mathrm{C}$. The condenser temperature is $40^{\circ} \mathrm{C}$ The mass flow rate of refrigerant around the cycle is $0.2 \mathrm{kg} / \mathrm{s}$, and the coefficient of performance is measured and found to be 2.3 . Find the power input to the compressor and the rate of entropy generation in the compressor process.
